Sigenergy Sigen Sensor Three Phase-CT120-DH

• Manufacturer Sigenergy
• IP Rating IP51

High-Accuracy Energy Monitoring

The Sigen Sensor Three Phase-CT120-DH provides 1% high-accuracy power detection, ensuring precise monitoring of energy consumption and grid interaction. This enables installers to optimise system performance and manage power flows efficiently.

Seamless Integration with Sigenergy Devices

This power sensor is designed for smooth integration with Sigenergy products, eliminating the need for additional setup. It supports AI-driven enhancements, making it future-ready for evolving smart energy applications.

Key Features

• High-accuracy power detection (1%)
• Supports three-phase grid connections (3P3W/3P4W)
• Voltage, current, and power accuracy within 0.5%-1%
• 100 A direct connection with built-in CT
• Fast 100ms data refresh rate for instant monitoring
• Export/import limitation support
• DIN Rail 35mm mounting for easy installation

Compact and Durable Design

Built for reliability, the sensor features an IP20 ingress protection rating, ensuring durability in various installation environments. Its compact form factor (72mm x 94.5mm x 65mm) and lightweight construction (0.20kg) make it easy to install.

Communication and Compatibility

The Sigen Sensor Three Phase-CT120-DH uses RS485 communication with Modbus RTU protocol, ensuring seamless connectivity with energy management systems. It operates across a wide voltage range (173-480V AC) and is compliant with EN 61010-1:2010 and EN 61010-2-030:2010 standards.

Ideal for Smart Energy Applications

With AI-driven capabilities and real-time data accuracy, the Sigenergy Sigen Sensor Three Phase-CT120-DH is an essential tool for optimising residential and commercial energy systems.
